Automatic fly ash brick making machine (FAM-2160)

Name: Automatic fly ash brick making machine (FAM-2160)
Brand: HARDIC MACHINERY
Price: 3600000 INR
Availability: InStock

3600000 INR/Unit

Get a Price/Quote

Product Details:

Product Type Automatic Fly Ash Brick Making Machine
General Use Manufacturing fly ash bricks for construction industry
Material High tensile steel structure
Capacity 30000-35000 bricks/8 hours
Weight (kg) 5500 kg
Type Fully Automatic
Computerized Yes
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Automatic fly ash brick making machine (FAM-2160) Price And Quantity

Minimum Order Quantity 1 Unit
Price 3600000 INR/Unit

Automatic fly ash brick making machine (FAM-2160) Product Specifications

Color Yellow & Blue
Vibration Type Heavy duty table vibration
PLC Control Yes
Weight (kg) 5500 kg
Vibration Frequency 50 Hz
General Use Manufacturing fly ash bricks for construction industry
Maximum Pressure 200 Ton
Voltage 415V, 3 Phase, 50 Hz
Capacity 30000-35000 bricks/8 hours
Type Fully Automatic
Computerized Yes
Product Type Automatic Fly Ash Brick Making Machine
Dimension (L*W*H) 2900 mm x 1900 mm x 3200 mm
Feature Robust design, energy efficient, low maintenance, high output
Machine Power 29 HP (approx)
Automatic Yes
Minimum Height 75 mm
Material High tensile steel structure
Maximum Height 230 mm
Pallet Size 900 mm x 600 mm x 18 mm
Number of Bricks 16 Bricks Per Stroke
Method Hydraulic Pressure

Automatic fly ash brick making machine (FAM-2160) Trade Information

Supply Ability 15 Unit Per Month
Delivery Time 3 Week

Product Description

Capacity	21000
Warranty	1 Year
Brick Raw Material	Concrete
Brand	mixwell
Model Name/Number	fam 2160
Tolerance	1 mm
Method	Hydraulic Pressure
Brick Type	Solid
Automation Grade	Automatic
Usage/Application	brick and paver block

We hold expertise in offering the superior quality Brick Making Machine Manufacturer In Asanol. We have used advanced fly ash brick making mechanism that operates on conveyor feeder and in built vibrators. Further, this machine features complete mild steel construction and superior output capacity.

Advanced Automation and High Productivity

The FAM-2160 is a technologically advanced, fully automatic brick making machine designed to streamline brick manufacturing. Its combination of fast mould cycling, computerized PLC controls, and an automatic feeder system ensures rapid, consistent production with minimal operator intervention, resulting in maximum output and workforce efficiency.

Exceptional Build Quality and Customization

Crafted with a high tensile steel frame, this machine is built for durability and heavy-duty performance. The FAM-2160 accommodates a standard brick size of 230 mm x 110 mm x 75 mm, but also offers customization options to meet specific project needs. Its robust design suits diverse construction environments, ensuring lasting productivity.

Operator-Friendly Controls and Low Maintenance

This machine features a user-intuitive touch screen control panel, enabling easy operation by just 23 operators per shift. With automatic pallet shifting, oil-cooled hydraulic systems, and reduced noise levels, the FAM-2160 prioritizes safety, energy efficiency, and minimal maintenance requirements for seamless ongoing use.

FAQs of Automatic fly ash brick making machine (FAM-2160):

Q: How does the FAM-2160 automatic fly ash brick making machine operate?

A: The FAM-2160 uses hydraulic pressure and heavy-duty table vibration to compact a mixture of fly ash, sand, cement, stone dust, lime, and gypsum into customizable brick shapes. The process is fully automated, managed through a PLC-based touch screen panel, with automatic feeding, pallet shifting, and optional stacking systems for efficient workflow.

Q: What raw materials are suitable for use in the FAM-2160 machine?

A: This machine can process a range of raw materials, including fly ash, sand, cement, stone dust, lime, and gypsum. This flexibility allows for the production of high-strength bricks tailored to various construction requirements.

Q: When should the hydraulic oil in the 350-liter tank be replaced or maintained?

A: Hydraulic oil should be checked regularly for contamination or degradation and typically replaced according to the manufacturers maintenance schedule or after every 1,000 to 1,500 operational hours, ensuring optimal performance and machine longevity.

Q: Where is after-sales service available for the FAM-2160 machine?

A: After-sales service for the FAM-2160 is available across India, including installation, commissioning, technical support, and spare parts, ensuring reliable operation and minimum downtime for distributors, manufacturers, and suppliers.

Q: What is the process for customizing brick sizes with this machine?

A: Brick size customization is achieved by using different moulds. The standard brick size is 230 mm x 110 mm x 75 mm, but the moulds can be changed as per requirement. The automatic mix feeding and pallet movement systems seamlessly adapt to various sizes.

Q: How many operators are required to use the FAM-2160 efficiently?

A: The FAM-2160 requires only 2 to 3 operators for efficient operation, thanks to its automated systems and user-friendly control panel, which reduce manual intervention and enhance productivity.

Q: What are the main benefits of using the FAM-2160 for brick manufacturing?

A: Key benefits include high output (up to 35,000 bricks per shift), robust energy-efficient design, consistent quality with minimal maintenance, a fully automatic process, and adaptability in brick sizes, making it an ideal choice for modern construction projects.
