Paver Block Making Machine

Name: Paver Block Making Machine
Brand: HARDIC MACHINERY
Price: 2800000 INR
Availability: InStock

2800000 INR/Unit

Get a Price/Quote

Product Details:

General Use Construction
Material Concrete
Type Hollow Block Making Machine
Computerized No
Automatic Yes
PLC Control No
Method Hydraulic Pressure
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Paver Block Making Machine Price And Quantity

Price 2800000 INR/Unit
Minimum Order Quantity 1 Unit

Paver Block Making Machine Product Specifications

Automatic Yes
Material Concrete
Type Hollow Block Making Machine
Warranty 1 year
Voltage 220 Volt (v)
PLC Control No
Method Hydraulic Pressure
General Use Construction
Computerized No

Paver Block Making Machine Trade Information

Supply Ability 15 Unit Per Month
Delivery Time 3 Week

Product Description

PAVER BLOCK MAKING MACHINE

We are Manufacturer, Supplier of Fly Ash Brick Making Machine (FAM-1080). This machine has an output of 12 Bricks at one time. Engineered to perfection, the Fly Ash Brick Making Machine (FAM-1080). comprises of sturdy vibrators, conveyors, pan mixers, etc. This model of Fly Ash Brick Making Machine (FAM-1080) has a production capacity of 17200 Bricks per shift.

Particulars	FAM-1080
1	Mixer Type	Pan Mixer
2	Mixer Capacity	Mixer Capacity
3	Pan Mixer Motor	7.5 HP / 5.59 KW
4	Pan Mixer Gear Box	HELICAL TYPE Gear Box
5	Mixer Speed	24-28 RPM
6	Mixing Arms	2 Nos. per Mixer
7	Crushing Rollers	2 Nos. per Mixer
8	Pan Mixer Feeding	Manual / Automatic Feeding Available as Optional
9	Pan Mixer Gate	Manual / Hydraulic Gate Available as Optional
10	Belt Conveyor Width	500 mm
11	Belt Conveyor Power	2 HP / 1.5 KW
12	Belt Conveyor Feeding Capacity	4 MT / Hour
13	Bricks Press Type	Automatic Hydraulic Bricks Press with HIGH VIBRATION Technology
14	Bricks Press Body	Heavy Duty Window type Body Fabricated from PIPE
15	Bricks Press Capacity	1080 -1100 Bricks/Hour
16	Bricks Press Tonnage	40 MT Max
17	Pressing Cylinder Bore Dia	125 mm
18	Bricks per Stroke	6 Bricks
19	Bricks Size(mm)	230 (L) X 110 (W) X 75 (H) Size Option Available
20	Hydraulic Motor	10 HP / 7.5 KW 9844419647
21	Trolley Feeder Motor	2 HP / 1.5 KW
22	Hyd. Oil Tank Capacity	220 ltrs
23	Hydraulic Valves	YUKEN Make / 24 DC
24	High Pressure Pump	YUKEN Make GEAR Pump
25	High Flow Pump	YUKEN Make GEAR Pump
26	VIBRATOR MOTOR	7.5 HP / 5.6 KW
27	Oil Cooling	Water Cooling
28	Control Panel	P L C Based Control Panel
29	Pallet Feeding	Automatic
30	Pallet Size	455 X 550 X 19 mm
Total Power		31 HP / 23.25 KW
LATEST GERMAN TECHNOLOGY HYDRAULIC + VIBRATION TYPE
FOUR IN ONE MODEL LIKE BRICK + PAVER BLOCK + SOLID BLOCK + HOLOLOW BLOCK

Brick & Block Production Capacity With Sizes
Sr No	Particulars	Image	Production Capacity		Pcs / Hr
Sr No	Particulars	Image	Sizes	Pcs/ Mould	Pcs / Hr
1	FLY ASH BRICK		230 X110 X75 MM	6	1080
2	FLY ASH BRICK		190 X190 X 90 MM	8	1440
3	I SHAPE PAVER BLOCK		200 X 165 X 60 MM	4	720
4	SOLID CONCRETE BLOCK		390 X 190 X 190 MM	2	360
5	HOLLOW CONCRETE BLOCK		390 X 190 X 190 MM	2	360

Efficient Concrete Block Production

Engineered for construction applications, the hydraulic Hollow Block Making Machine delivers robust, high-quality concrete paver blocks with minimal manual intervention. Its automatic operations enhance productivity while ensuring consistent block dimensions and strength for reliable construction results.

Designed for Indian Market Needs

Without the complexity of PLC control or computerization, this paver block making machine suits the preferences of Indian users seeking straightforward, low-maintenance solutions. Manufacturers, distributors, and suppliers benefit from easy installation and simple operation backed by a one-year warranty.

FAQs of Paver Block Making Machine:

Q: How does the Hollow Block Making Machine operate without PLC control?

A: The machine uses straightforward hydraulic pressure mechanisms, managed through manual or electromechanical controls, which eliminates the need for PLC systems. This makes it easier to operate and maintain, especially for users preferring simple automation.

Q: What materials are required for producing blocks with this machine?

A: The primary material used is concrete, which is molded into hollow paver blocks by the machine using hydraulic pressure. No additional computerized inputs or complex materials are needed; standard concrete mix suffices for operation.

Q: When is it ideal to use this machine in construction projects?

A: This automatic Hollow Block Making Machine is best utilized when consistent production of concrete paver blocks is needed, particularly for ongoing building or infrastructure projects that require uniformity and reliability in block quality.

Q: Where can distributors, manufacturers, and suppliers source this machine in India?

A: The machine is widely available through established industrial equipment suppliers, manufacturers, and authorized distributors offering construction machinery in various regions across India.

Q: What is the block-making process with hydraulic pressure?

A: Concrete is fed into the machines mold section, after which hydraulic pressure is applied to form compact, hollow blocks. This ensures precise shaping and solid strength, all achieved automatically without computerized controls.

Q: How does using this machine benefit construction businesses?

A: Employing this Hollow Block Making Machine speeds up block production, delivers consistent quality, reduces labor requirements, and minimizes operational complexity, thereby improving overall project efficiency.
